BT3564 - Battery Tester, 1000 V, 3 mOhm

The Hioki BT3564 Battery Tester is an advanced measurement instrument ideal for fully automated testing of large battery packs, particularly in electric vehicles (xEVs).

BT3564 - Battery Tester, 1000 V, 3 mOhm

BT3564 - Battery Tester, 1000 V, 3 mOhm

BT3564 - Battery Tester, 1000 V, 3 mOhm

BT3564 - Battery Tester, 1000 V, 3 mOhm

BT3564 - Battery Tester, 1000 V, 3 mOhm

€5,118.00

Content: 1 Each

Available in 21 days

€5,118.00

BT3564 - Battery Tester, 1000 V, 3 mOhm

Product number: BT3564

GTIN/EAN: 4536036011759

Length: 295 mm

Width: 215 mm

Height: 80 mm

Weight: 2.4 kg

Product information BT3564 - Battery Tester, 1000 V, 3 mOhm

The Hioki BT3564 Battery Tester is an advanced measurement instrument ideal for fully automated testing of large battery packs, particularly in electric vehicles (xEVs). It simultaneously measures internal resistance and open-circuit voltage (OCV) with resistance ranges from mΩ to 3 kΩ and voltage ranges up to 1000 V DC.

Featuring a fast measurement speed of approximately 5 ms and a 2 ms sampling rate in ""Extra-FAST"" mode, the BT3564 offers outstanding testing efficiency. It is equipped with RS-232C, GP-IB, EXT-I/O, and Analog Out interfaces, ensuring easy integration into various systems. Its electrostatic-resistant design and spark discharge reduction feature enhance reliability and safety during high-voltage testing.

Technical Details:

Resistance measuring range: to 3 kΩ
Voltage measuring range: Up to 1000 V DC
Measurement speed: 5 ms
Measurement Frequency: 1 kHz ±0.2 Hz
Sampling rate: 2 ms in ""Extra-FAST"" mode
Interfaces: RS-232C, GP-IB, EXT-I/O, Analog Out
Features: Electrostatic-resistant design, spark discharge reduction

BT3564
Instruction manual
Mains cable
Precautions for operation
